XCPoE-MASTER, imc Fieldbus Interface - XCPoE Master
The XCPoE Master-Slave is Configured as a XCPoE Master ex-factory. With new imc software versions a flexible configuration of the interface will be possible.
Features:
- imc XCPoE Master-Slave, Fieldbus Interface
- Transfer Protocol: XCP - Parts 1 Through 4
- Ethernet Enables High-Speed Data Transfer
- Process Vector Used as Signal Source
- Fully Supported by imc STUDIO Software
- Occupies 1 Fieldbus Slot
- Isolated
Manufacturer: imc Test & Measurement
Quote
Datasheet
Specifications
Models & Accessories
Downloads
Similar Products
XCPoE-MASTER - Specifications
| Family | imc CRFX |
| Unit Type | Module |
| Field Interface | XCPoE |
| Min Temperature | -10 °C |
| -40 °C | |
| Max Temperature | 55 °C |
| 85 °C |
XCPoE-MASTER - Models & Accessories
Models
| CRFX/XCPoE-MASTER | For CRFX Base Unit, XCPoE Master-Slave Interface, -10°C to 55°C |
| CRFX/XCPoE-MASTER-ET | For CRFX Base Unit, XCPoE Master-Slave Interface, -40°C to 85°C |
XCPoE-MASTER - Downloads
Digital Fieldbus Datasheet Datasheet |
imc Company Brochure Brochure |
TD_Digital_Fieldbus_connection_Options Datasheet |
