PROFIBUS, imc Fieldbus Interface - Profibus
The PROFIBUS fieldbus interface has achieved worldwide prevalence as an industrial fieldbus for production and process automation. Sensors, actuators and multiple distributed control systems can be networked at data rates of up to 12 Mbit/s.
Features:
- imc Profibus, Fieldbus Interface
- Transfer Protocol: DPV0, DPV1
- Networking Enables High-Speed Data Transfer
- Fully Supported by imc STUDIO Software
- Occupies 1 Fieldbus Slot
- Isolated
Manufacturer: imc Test & Measurement
Quote
Datasheet
Specifications
Models & Accessories
Downloads
Similar Products
PROFIBUS - Specifications
| Family | imc CRFX |
| Unit Type | Module |
| Field Interface | Profibus |
| Min Temperature | -10 °C |
| -40 °C | |
| Max Temperature | 55 °C |
| 85 °C |
PROFIBUS - Models & Accessories
Models
| CRFX/PROFIBUS | For CRFX Base Unit, Profibus Interface, -10°C to 55°C |
| CRFX/PROFIBUS-ET | For CRFX Base Unit, Profibus Interface, -40°C to 85°C |
PROFIBUS - Downloads
Digital Fieldbus Datasheet Datasheet |
