CRSL/DI2-16, imc CRONOS-SL Chassis Module
The CRSL/DI2-16 chassis module enables sampling of digital inputs having TTL/CMOS or 24 V logic levels. The level can be set separately for each group of eight inputs. The groups are jointly isolated from the system.
Features:
- imc CRONOS-SL Digital Input Chassis Module
- 16 Digital Input Channels, Isolated
- TTL or 24 V Logic Level Inputs
- Differential Inputs
- Occupies 1 Slot
Manufacturer: imc Test & Measurement
Quote
Brochure
Specifications
Downloads
Similar Products
CRSL/DI2-16 - Specifications
| Family | imc CRONOS-SL |
| Unit Type | Module |
| Input Type | Digital |
| Digital Inputs | 16 |
| Max Sample Rate | 10 kHz |
| Resolution | 16-bit |
| Min Temperature | -40 °C |
| Max Temperature | 85 °C |
| IP Rating | IP65 |
CRSL/DI2-16 - Downloads
imc Company Brochure Brochure |
imc CRONOS SL, DI2-16 Datasheet Datasheet |
