BA2 Z-Y, Shibaura_Toshiba CARTESIAN Robot, Multi-Axis (Discontinued)
Sensible alternative to costly industrial robots that are difficult to program and operate. Toshiba's Building block systems allows for all digital Multi-Axis configuration with a variety of power options.
Features:
- Cost Effective
- Easy Programming
- Plug and Play Functionality
- Digital Multi-axis configuration
- Variety of power options
- Max Stroke 1,500 x 1,000mm
- Max Payload of 38Kg
Manufacturer: Shibaura Machine Co. Ltd. - TM Robotics
Quote
Datasheet
Description
Applications
Models & Accessories
Downloads
BA2 Z-Y - Description
BA2 Z-Y - Applications
Shibaura's BA2 Robots can be used for a diverse range of application needs.
BA2 Z-Y - Models & Accessories
Models
| BA2 Z-Y | Multi Axis Robot |
| BA2-A1-C2A | Z Axis (Ball Screw) Y Axis (Ball Screw) |
| BA2-A3-C2B | Z Axis (Ball Screw) Y Axis (Ball Screw) |
| BA2-A5-C2A | Z Axis (Ball Screw) Y Axis (Ball Screw) |
| BA2-A5-C2B | Z Axis (Ball Screw) Y Axis (Ball Screw) |
| BA2-A1-L2A | Z Axis (Timing Belt) Y Axis (Timing Belt) |
| BA2-A3-L2A | Z Axis (Timing Belt) Y Axis (Timing Belt) |
| BA2-A3-L2B | Z Axis (Timing Belt) Y Axis (Timing Belt) |
| BA2-A5-L2A | Z Axis (Timing Belt) Y Axis (Timing Belt) |
| BA2-A5-L2B | Z Axis (Timing Belt) Y Axis (Timing Belt) |
BA2 Z-Y - Downloads
BA2 Z-Y Datasheet |
