GM80-TG, Desktop Indicator & Data Logger
GM 80-TG is a Desktop Indicator & Data Logger for Strain Gage based Sensors, ma signals or Voltages. 3 opto coupled input functions such as data logging, issue of interface, delete buffer, tare or second limit value set
Features:
- Input Signals, 0.35 to 3.3 mV/V, 0…±1 V, 0…±5 V or 0/4…20 mA
- Supply Power, 90…264 V AC or 16…30 V DC
- High Measuring Accuracy; 0.1% F.S. with 16 bit A/D
- Fast Data Logging of up to 1000/sec, for 3000 measurements
- Logging values can be exported by the RS232 or USB interface
- Functions such as tare & Min.-Max. are available
Manufacturer: Lorenz Messtechnik GmbH
Quote
Datasheet
Specifications
Downloads
Related Products
GM80-TG - Specifications
| Input Type | ±10 V DC |
| Strain Gage, mV/V | |
| mA dc | |
| # of Inputs | 1 |
| Excitation | 5 Vdc |
| 10 vdc | |
| 0 - 12 V DC | |
| Supply Power | 24 - 30 V DC |
| 115 V AC | |
| 230 V AC |
GM80-TG - Downloads
GM80-TG Desktop Indicator & Data Logger Vdc Strain & ma Datasheet |
GM80 TG-PA-VS_GM80-TG Indicator & Data Logger Software Datasheet |
