EPSI-AX-V, Strain Sensor - Voltage Output
This sensor is well suited to outdoors and harsh environment applications such as on-board weighing of vehicles, overload control on lift trucks, sea port installations, beam deflection of engineering structures & level of tanks or outdoor silos.
Features:
- Made of stainless steel & sealed to IP68
- Very stiff design & High Output Sensitivity
- Digital Temperature Compensation of the thermal expansion
- Operates from -40 up to +70°C
- Power required, 11 to 28 Vdc
- Output of 0 to 20 ma for ±500 µm/m, (microstrain)
Manufacturer: Scaime
Quote
Datasheet
Applications
Downloads
Related Products
EPSI-AX-V - Applications
Silo Weight and Level Measurement
EPSI-AX-V - Downloads
EPSIAX-V-Strain Sensor Datasheet |
EPSI-Mounting & Accessoires Product Note |
Silo Weighing Extensometer Tech Note |
